700R4 to NP203 Kit

700R4 to NP203 Kit

1997 and later 4l60 to NP203 Kit

1997 and later 4l60 to NP203 Kit

1996 and earlier 4l60 to NP203 Kit

What you need to adapt a 4l60e to a NP203

In stock
SKU
1996 and earlier 4l60 to NP203 Kit
Grouped product items
Product Name Qty
700R4/4L60E Short output shaft
$170.00
700R4 spacer, 1-7/8 Inch with bolts
$90.00
Adapter plate for TH400/NP203
$175.00

Adapting a 4l60e to a NP203 is either installing the spacer or the shorter output shaft onto the 4l60e. Only one of those needs to be used, not both.

Then bolting up with a TH350/NP203 adapter.


A 27 spline input needs to be installed into the NP203 if it doesn’t have one already.

Keep in mind you will need a vss added to the np203 (this is something we do not offer) to keep the transmission shifting happily. If you are doing a doubler system we offer the service of adding a vss to the np205.

If you already have one of the items on this list and do not need to order just put a (0) in the quantity.
